BLITZ ZZ-R Coilovers (FK8/FL5)

A height-adjustable suspension kit with 32-stage damping force adjustment, designed for versatile use.

Balancing performance and ride comfort at a high level, it can adapt to various driving scenarios, from street to circuit.

Product Features:

Height-adjustable suspension kit with single-tube (monotube) construction.

Equipped with a 32-stage damping force adjustment mechanism, allowing for a wide range of damping adjustments. It is suitable for all driving scenarios, from street to circuit.

Uses aluminum upper mounts, lock seats, and brackets (in some parts) to achieve both high strength and lightweight design.

Adopts a φ44 large-diameter piston unique to single-tube construction, suppressing damping delay. This provides a supple ride quality and responsiveness (except for some vehicle models).

Compatible with cartridge-type overhauls with protruding cartridges. This allows for the replacement of consumable parts with a smooth and different approach.

Product Specifications

Front / Rear

Damping Force Adjustment: 32-stage adjustment / 32-stage adjustment

Height Adjustment: Yes (✓) / Yes (✓)

Shock Absorber Configuration: Coilover / Separate Type

Upright or Inverted: Upright / Upright

Upper Mount: Adjustable Pillow / Reinforced Rubber

Spring Rate: 12.0 kgf/mm / 10.0 kgf/mm

Spring Free Length: 160 mm / 165 mm

Spring Type: ST / BS

Height Adjustment Range: -50 to 0 mm / -40 to -10 mm
