AMUSE R1TITAN Performa Catback Exhaust (FL5)

Build to order item, 1-3 months

A Tail Gold Ring - approximately half of the exit section in blue

B Tail Gold Ring - entire exit section in blue

Main Diameter: 76.3Φ

Sub-Tail Inner Pipe Diameter: 70Φ

Silencer Type: Dual In-Line Cannon Silencer

Inner Pipe Diameter: 70mm

Tail Diameter: Dual 130Φ

Remarks:

Weight: 8.5kg

Stock Weight: 18.02kg

Box Size: 2200mm × 220mm × 660mm

Accessories: Special Mounting Titanium Stay & Special Titanium Bolt Nut

Designed for Closed Courses & Overseas Users: FL5 Civic TYPE R R1TITAN Performa Gold Ring

Considering the enlargement of the OEM exhaust pipe, we conducted multiple tests, and as a result, we designed the Performa with a main pipe diameter of 76.3Φ. In the center pipe, there is one large-capacity silencer, and on the front side, there is another silencer installed.

The main silencer is designed with a megaphone structure, ensuring a capacity of over 85Φ with two silencers.

To ensure the minimum ground clearance, we manufactured it in the OEM layout as much as possible, following the shape along the floor

FL5 CIVIC TYPE R R1TITAN Performa Gold Ring designed for closed course & overseas users

Considering that the stock muffler has a larger diameter pipe, Performa was made with a 76.3Φ main pipe as a result of repeated tests.

The center pipe is fitted with one high capacity silencer and another silencer on the front side.

The two main silencers are of megaphone construction with a capacity of over 85Φ.

The tail end is 130Φ x 2 as a size that can fully show off the muffler even with two silencers.

In order to secure minimum ground clearance, the muffler is made in a shape that follows the floor as much as possible while keeping the factory layout.

This model is made without compromising on appearance, weight reduction, and sound quality.

Tail end logo is optional.

Reference volume

Sports mode at 3500 rpm 89-91db

Volume at accelerator off from 3500 rpm in sports mode: 93db

When ordering, please specify

1. without front pipe silencer NO1

2.Without front pipe silencer NO2

3. without both NO1 and NO2 front pipe silencers as an option.
